overview
The OMSA Series accepts Ø12.7 mm (0.5 inch) optical components. Applications include mounting and tip/tilt adjustment for mirrors, lenses, and filters.
The design features a spring-loaded structure and M4×0.25 fine adjustment screws for angular control. M4 threaded holes and dowel holes allow integration with mechanical assemblies.
This series offers three retention methods: SM05 threading, setscrew, or setscrew with flexure shim. Two configurations are available: 2-axis or 3-axis. The optical bore is 12.7 mm. Dimensions are approximately 25.7 mm × 25.7 mm, suitable for compact setups.
Features
Spring-loaded mechanism with fine-thread screws for tip/tilt adjustment.
Locking nuts secure the position after adjustment
Side M4 threaded holes and dowel holes enable positioning with supports or bases.
Three retention options: SM05 thread, side setscrew, or setscrew with flexure clamp
Standard 0.5" (12.7 mm) aperture; dimensions approx. 25.7 mm × 25.7 mm
